Small size, 40 grams ultra-lightweight, universal fixing holes in the industry
Conforms to USB3.0 ultra-high-speed communication protocol, with a maximum speed of 440MByte/s Built-in large-capacity frame buffer, stable and reliable real-time transmission
Ultra-low power consumption and strong stability Typical power consumption is less than 2w
Third-party vision development software, based on uSB3.0 Vision, GenlCam development compatible with HALCON, LabView, openCv, etc.
| Model No. | Pixel(MP) | Resolution | Sensor Size | Sensor Model | Pixel size(μm) | Maximum frame rate(fps) | Shutter Type | Sensor Type | Data Interface | Mono | Color |
| LANO-AE30-721UC | 0.3 | 64O×480 | 1/5" | SC130GS/SC132GS | 4 | 721 | Global | CMOS | USB3.0 | √ | |
| LANO-AE131-214UC | 1.31 | 1280×1024 | 1/2.7" | SC130GS/SC132GS | 4 | 213.9 | Global | CMOS | USB3.0 | √ | |
| LANO-AE230A-4OUM | 2.3 | 1920×1200 | 1/1.2" | IMX249 | 5.86 | 40 | Global | CMOS | USB3.0 | √ | |
| LANO-AE50O-51UC | 5 | 2448×2048 | 2/3" | IMX264 | 3.45 | 51 | Global | / | USB3.0 | √ | |
| LANO-AE5OO-7OUM | 5 | 2448×2048 | 2/3" | R52S1DAOLT | 3.45 | 70 | Global | CMOS | USB3.0 | √ | |
| LANO-AE5O4-30UC | 5 | 2592×1944 | 1/2.5" | ARO521 | 2.2 | 31 | Rolling | CMOS | USB3.0 | √ | |
| LANO-AE520-27UM | 5.2 | 2640×1978 | 4/3" | / | 6.9 | 27 | Rolling | CMOS | USB3.0 | √ | |
| LANO-AE630-70UC | 6.3 | 3072×2048 | 1/1.8" | IMX178 | 2.4 | 71 | Global | CMOS | USB3.0 | √ | |
| LANO-AE1200-32UC | 12 | 4096×3072 | 1" | XGS1200 | 3.2 | 31.18 | Global | CMOS | USB3.0 | √ | |
| LANO-AE2000-20UC | 20 | 5280×3956 | 4/3" | IMX269 | 3.45 | 20 | Rolling | CMOS | USB3.0 | √ | |
| LANO-AE2000-22UC | 20 | 5480×3648 | 1" | IMX183 | 2.4 | 22 | Rolling | CMOS | USB3.0 | √ |
