Spectral Resolution up to 2nm Up to 600 spectral channels
High sensitivity and superior signal-to-noise ratio
Simultaneously and quickly acquire spectral and image information
The spectrum acquisition interval can be set flexibly USB3.0 data interface, plug and play
Small and compact structure, solid and reliable, suitable for integration in complex application scenarios
| Product Number | LANO-SP400-1000A | LANO-SP400-1000B |
| Spectral Range | 400-1000nm | 400-1000nm |
| Sampling Interval | 1nm | 1nm |
| Spectral Resolution | 2nm | 2nm |
| Optical Lens | 35mm scientific grade fixed focus lens(optional 16mm fixed focus lens) | 50mm/35mm/16mm (fixed focus lens optional) |
| Numerical Aperture | F/2.8 | F/4 |
| Slit size | 30μm x 7mm | 25μm x 6.5mm |
| Number of Spectral Channels | 600 | 600 |
| Number of Spatial Channels | 1200 | 1000 |
| Effective Cell size | 6.9μm x6.9μm | 5.86μm x 5.86μm |
| Data Depth | 12bits | 12 bits |
| Max Frame Rate | 165 fps | 165 fps@full 320fps@binning |
| Shutter Mode | global shutter | global shutter |
| Lens Mount | standard C interface | Standard C interface |
| Device Interface | USB3.0 | USB3.0 |
| Operating Temperature | 0℃-45℃ | 0℃-45℃ |
| Dimensions(WxHxD, without lens) | 120mm* 85mm *220mm | 65mm* 52.5mm *136mm |
| Weight (without lens) | <2.0kg | 520g |
| Power Consumption | <3.5W | <3.5W |
| External Power Supply | Powered by USB3.0 | Powered by USB3.0 |
